EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 366
PP_ERROR
0xE0017E28
10.8.7 PP_ERROR
P-Port Error Indicator Register
This register indicates the error codes associated with PIB_INTR.PIB_ERR, MMC_ERR and GPIF_ERR. The different values
for these error codes will be documented in the P-Port BROS document. This register is also visible to firmware as PIB_ER-
ROR.
14:10 GPIF_ERR_CODE[4:0] Mirror of corresponding field in PIB_ERROR
5:0 PIB_ERR_CODE[5:0] Mirror of corresponding field in PIB_ERROR
PP_ERROR P-Port Error Indicator Register 0xE0017E28
b15 b14 b13 b12 b11 b10 b9 b8
GPIF_ERR_CODE[4:0]
RRRRR
R/W R/W R/W R/W R/W
00000
PP_ERROR P-Port Error Indicator Register
b7 b6 b5 b4 b3 b2 b1 b0
PIB_ERR_CODE[5:0]
RRRRRR
R/W R/W R/W R/W R/W R/W
000000
