Cypress EZ-USB FX3 User Manual

EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 295
PIB_DLL_CTRL
0xE0010028
10.6.9 PIB_DLL_CTRL
DLL Configuration Register
This register configures the DLL phases and enables the DLL.
31 ENABLE_RESET_ON_ERR 0 Hardware does not reset the DLL when DLL code overrun/underrun occurs
1 Hardware resets the DLL when DLL code overrun/underrun occurs
30 DLL_RESET_N Resets the DLL
0 DLL is reset
1 DLL is not reset
continued on next page
PIB_DLL_CTRL DLL Configuration Register 0xE0010028
b31 b30 b29 b28 b27 b26 b25 b24
ENABLE_RESET
_ON_ERR
DLL_RESET_N
R/W R/W
RR
00
PIB_DLL_CTRL DLL Configuration Register
b23 b22 b21 b20 b19 b18 b17 b16
PIB_DLL_CTRL DLL Configuration Register
b15 b14 b13 b12 b11 b10 b9 b8
PIB_DLL_CTRL DLL Configuration Register
b7 b6 b5 b4 b3 b2 b1 b0
DLL_STAT HIGH_FREQ ENABLE
RR/WR/W
WR R
000
Bit Name Description
