EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 344
GPIF_ALPHA_STAT
0xE0014110
10.7.37 GPIF_ALPHA_STAT
Alpha Status Register
Provides the current state of the 8 Alphas (state machine early outputs).
7:0 ALPHA[7:0] Current value of the Alpha signals
GPIF_ALPHA_STAT Alpha Status Register 0xE0014110
b31 b30 b29 b28 b27 b26 b25 b24
GPIF_ALPHA_STAT Alpha Status Register
b23 b22 b21 b20 b19 b18 b17 b16
GPIF_ALPHA_STAT Alpha Status Register
b15 b14 b13 b12 b11 b10 b9 b8
GPIF_ALPHA_STAT Alpha Status Register
b7 b6 b5 b4 b3 b2 b1 b0
ALPHA[7:0]
RRRRRRRR
R/W R/W R/W R/W R/W R/W R/W R/W
00001010
Bit Name Description
