EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 363
PP_INTR_MASK
0xE0017E1C
10.8.4 PP_INTR_MASK
P-Port Interrupt Mask Register
This register holds bits required to control PMMC interface.
15 WAKEUP 1 Forward EVENT onto INT line
14 WR_MB_EMPTY 1 Forward EVENT onto INT line
13 RD_MB_FULL 1 Forward EVENT onto INT line
12 DMA_READY_EV 1 Forward EVENT onto INT line
11 DMA_WMARK_EV 1 Forward EVENT onto INT line
7GPIF_ERR 1 Forward EVENT onto INT line
5PIB_ERR 1 Forward EVENT onto INT line
4GPIF_INT 1 Forward EVENT onto INT line
3 SOCK_AGG_BH 1 Forward EVENT onto INT line
2 SOCK_AGG_BL 1 Forward EVENT onto INT line
1 SOCK_AGG_AH 1 Forward EVENT onto INT line
0 SOCK_AGG_AL 1 Forward EVENT onto INT line
PP_INTR_MASK P-Port Interrupt Mask Register 0xE0017E1C
b15 b14 b13 b12 b11 b10 b9 b8
WAKEUP WR_MB_EMPTY RD_MB_FULL DMA_READY_EV
DMA_WMARK_
EV
R/W R/W R/W R/W R/W
RRRRR
00100
PP_INTR_MASK P-Port Interrupt Mask Register
b7 b6 b5 b4 b3 b2 b1 b0
GPIF_ERR PIB_ERR GPIF_INT SOCK_AGG_BH SOCK_AGG_BL SOCK_AGG_AH SOCK_AGG_AL
R/W R/W R/W R/W R/W R/W R/W
R
RRRRRR
0
000000
Bit Name Description
