Cypress EZ-USB FX3 User Manual

EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 438
OHCI_COMMAND_STATUS
0xE003202C
10.14.12 OHCI_COMMAND_STATUS
Command and Status Register
19 HC_HALTED This bit is a zero whenever the Run/Stop bit is a one.
The HC sets this bit to one after it has stopped executing as a result of the Run/Stop bit being set to 0
by software.
18 RS Run/Stop (Replacing the OwnerShipChangeRequest)
0Stop
1Run
17:16 SOC SchedulingOverrunCount
OHCI_COMMAND_STATUS Command and Status Register 0xE003202C
b31 b30 b29 b28 b27 b26 b25 b24
OHCI_COMMAND_STATUS Command and Status Register
b23 b22 b21 b20 b19 b18 b17 b16
HC_HALTED RS SOC[1:0]
RR/WR R
R/W R R/W R/W
1000
OHCI_COMMAND_STATUS Command and Status Register
b15 b14 b13 b12 b11 b10 b9 b8
OHCI_COMMAND_STATUS Command and Status Register
b7 b6 b5 b4 b3 b2 b1 b0
Bit Name Description
