EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 379
PP_BUF_SIZE_CNT
0xE0017E??
10.8.17 PP_BUF_SIZE_CNT
P-Port Socket Buffer Size or Count Register
These registers contain the buffer size or count, depending on direction, of the corresponding socket (0..31). This is equal to
buffer_size/buffer_count in the corresponding DSCR_SIZE/DSCR_COUNT register. These registers are present in the
PMMC P-Port space only! No registers exist in the PP space, only the socket registers are read for this from the adapter. The
value of PP_BUF_SIZE_CNT is valid only if the PP_SOCK_STAT indicates ready for the corresponding socket.
15:0 SIZE_CNT[15:0] Buffer size of the corresponding write socket (0..31)
PP_BUF_SIZE_CNT P-Port Socket Buffer Size or Count Register 0xE0017E??
b15 b14 b13 b12 b11 b10 b9 b8
SIZE_CNT[15:8]
R R/W R/W R/W R/W R/W R/W R/W
W R/W R/W R/W R/W R/W R/W R/W
00000000
PP_DMA_SIZE P-Port DMA Transfer Size Register
b7 b6 b5 b4 b3 b2 b1 b0
SIZE_CNT[7:0]
R/W R/W R/W R/W R/W R/W R/W R/W
R/W R/W R/W R/W R/W R/W R/W R/W
00000000
Bit Name Description
