EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 339
GPIF_INGRESS_ADDRESS
0xE00140DC
10.7.33 GPIF_INGRESS_ADDRESS
Thread Ingress Address Register
There are four GPIF_INGRESS_ADDRESS registers. The address of each is calculated as GPIF_INGRESS_ADDRESS(x) =
0xE00140DC + (x*0x4). Hence GPIF_INGRESS_ADDRESS(0) is at address 0xE00140DC, GPIF_INGRESS_ADDRESS(1)
is at address 0xE00140DC + 0x4 and so on. The definition of each of these is the same.
Holds ingress address for the active socket in a thread.
31:0 ADDRESS[31:0] Ingress address
GPIF_INGRESS_ADDRESS Thread Ingress Address Register 0xE00140DC
b31 b30 b29 b28 b27 b26 b25 b24
ADDRESS[31:24]
RRRRRRRR
R/W R/W R/W R/W R/W R/W R/W R/W
00000000
GPIF_INGRESS_ADDRESS Thread Ingress Address Register
b23 b22 b21 b20 b19 b18 b17 b16
ADDRESS[23:16]
RRRRRRRR
R/W R/W R/W R/W R/W R/W R/W R/W
00000000
GPIF_INGRESS_ADDRESS Thread Ingress Address Register
b15 b14 b13 b12 b11 b10 b9 b8
ADDRESS[15:8]
RRRRRRRR
R/W R/W R/W R/W R/W R/W R/W R/W
00000000
GPIF_INGRESS_ADDRESS Thread Ingress Address Register
b7 b6 b5 b4 b3 b2 b1 b0
ADDRESS[7:0]
RRRRRRRR
R/W R/W R/W R/W R/W R/W R/W R/W
00000000
Bit Name Description
