EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 595
GPIO_INTR
0xE00013E8
10.22.6 GPIO_INTR
GPIO Interrupt Vector for PINs Register
One bit for each GPIO PIN structure indicating its interrupt status. The actual pin associated with a PIN structure (if any) is set
in GCTL_GPIO_COMPLEX.
7 INTR7 Set by hardware when corresponding STATUS asserts, cleared by software.
6 INTR6 Set by hardware when corresponding STATUS asserts, cleared by software.
5 INTR5 Set by hardware when corresponding STATUS asserts, cleared by software.
4 INTR4 Set by hardware when corresponding STATUS asserts, cleared by software.
3 INTR3 Set by hardware when corresponding STATUS asserts, cleared by software.
2 INTR2 Set by hardware when corresponding STATUS asserts, cleared by software.
1 INTR1 Set by hardware when corresponding STATUS asserts, cleared by software.
0 INTR0 Set by hardware when corresponding STATUS asserts, cleared by software.
GPIO_INTR GPIO Interrupt Vector for PINs 0xE00013E8
b31 b30 b29 b28 b27 b26 b25 b24
GPIO_INTR GPIO Interrupt Vector for PINs
b23 b22 b21 b20 b19 b18 b17 b16
GPIO_INTR GPIO Interrupt Vector for PINs
b15 b14 b13 b12 b11 b10 b9 b8
GPIO_INTR GPIO Interrupt Vector for PINs
b7 b6 b5 b4 b3 b2 b1 b0
INTR7 INTR6 INTR5 INTR4 INTR3 INTR2 INTR1 INTR0
RRRRRRRR
WWWWWWWW
00000000
Bit Name Description
