EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 443
OHCI_FM_REMAINING
0xE0032040
10.14.17 OHCI_FM_REMAINING
Current Value of Remaining Frame Count Register
31 FRT FrameRemainingToggle
14:0 FR[14:0] FrameRemaining
OHCI_FM_REMAINING Current Value of Remaining Frame Count Register 0xE0032040
b31 b30 b29 b28 b27 b26 b25 b24
FRT
R
R/W
0
OHCI_FM_INTERVAL OHCI Frame Control Information Register
b23 b22 b21 b20 b19 b18 b17 b16
OHCI_FM_INTERVAL OHCI Frame Control Information Register
b15 b14 b13 b12 b11 b10 b9 b8
FR[14:8]
RRRRRRR
R/W R/W R/W R/W R/W R/W R/W
0000000
OHCI_FM_INTERVAL OHCI Frame Control Information Register
b7 b6 b5 b4 b3 b2 b1 b0
FR[7:0]
RRRRRRRR
R/W R/W R/W R/W R/W R/W R/W R/W
00000000
Bit Name Description
