EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 493
LNK_COMPLIANCE_PATTERN_0
0xE0033138
10.15.16 LNK_COMPLIANCE_PATTERN_0
Compliance Pattern CP0 Register
This register determines the behavior of the FX3 device when sending any of the USB 3.0 compliance patterns. The default
value of this register corresponds to compliance pattern 0.
12 TXONESZEROS Enable TXONESZEROS (PIPE PHY Transmit Signal)
11 LFPS LFPS On/Off
10 DEEMPHASIS De-emphasis On/Off
9 SCRAMBLED Scramble On/Off
8K_D Symbol Type
0 Data (D)
1Symbol (K)
7:0 CP[7:0] Compliance Pattern
LNK_COMPLIANCE_PATTERN_0 Compliance Pattern CP0 Register 0xE0033138
b31 b30 b29 b28 b27 b26 b25 b24
LNK_COMPLIANCE_PATTERN_0 Compliance Pattern CP0 Register
b23 b22 b21 b20 b19 b18 b17 b16
LNK_COMPLIANCE_PATTERN_0 Compliance Pattern CP0 Register
b15 b14 b13 b12 b11 b10 b9 b8
TXONESZEROS LFPS DEEMPHASIS SCRAMBLED K_D
R/W R/W R/W R/W R/W
RRRRR
00110
LNK_COMPLIANCE_PATTERN_0 Compliance Pattern CP0 Register
b7 b6 b5 b4 b3 b2 b1 b0
CP[7:0]
R/W R/W R/W R/W R/W R/W R/W R/W
RRRRRRRR
0x00
Bit Name Description
