EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 506
PROT_INTR_MASK
0xE0033408
10.16.3 PROT_INTR_MASK
Protocol Interrupts Mask Register
Controls whether protocol layer interrupts are reported to the CPU.
15 SET_ADDR0_EN 1 Report interrupt to CPU
14 EP0_STALLED_EN 1 Report interrupt to CPU
13 LMP_INVALID_PORT_CFG_EN 1 Report interrupt to CPU
12 LMP_INVALID_PORT_CAP_EN 1 Report interrupt to CPU
11 STATUS_STAGE 1 Report interrupt to CPU
10 HOST_ERR_EN 1 Report interrupt to CPU
9SUTOK_EN 1 Report interrupt to CPU
8ITP_EN 1 Report interrupt to CPU
continued on next page
PROT_INTR_MASK Protocol Interrupts Mask Register 0xE0033408
b31 b30 b29 b28 b27 b26 b25 b24
PROT_INTR_MASK Protocol Interrupts Mask Register
b23 b22 b21 b20 b19 b18 b17 b16
PROT_INTR_MASK Protocol Interrupts Mask Register
b15 b14 b13 b12 b11 b10 b9 b8
SET_ADDR0_EN
EP0_STALLED_
EN
LMP_INVALID_
PORT_CFG_EN
LMP_INVALID_
PORT_CAP_EN
STATUS_STAGE HOST_ERR_EN SUTOK_EN ITP_EN
R/W R/W R/W R/W R/W R/W R/W R/W
RRRRRRRR
00000000
PROT_INTR_MASK Protocol Interrupts Mask Register
b7 b6 b5 b4 b3 b2 b1 b0
TIMEOUT_HOST_
ACK_EN
TIMEOUT_PING_
EN
TIMEOUT_PORT_
CFG_EN
TIMEOUT_PORT_
CAP_EN
LMP_PORT_CFG
_EN
LMP_PORT_CAP
_EN
LMP_UNKNOWN_
EN
LMP_RCV_EN
R/W R/W R/W R/W R/W R/W R/W R/W
RRRRRRRR
00000000
Bit Name Description
