Cypress EZ-USB FX3 - GCTL_WPU_CFG

EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 247
GCTL_WPU_CFG
0xE0051020
10.4.5 GCTL_WPU_CFG
I/O Pull-Up Configuration Register
continued on next page
GCTL_WPU_CFG I/O Pull-Up Configuration Register 0xE0051020
b63 b62 b61 b60 b59 b58 b57 b56
WPU[59:56]
R/W R/W R/W R/W
R R R R
0 0 0 0
GCTL_WPU_CFG I/O Pull-Up Configuration Register
b55 b54 b53 b52 b51 b50 b49 b48
WPU[55:48]
R/W R/W R/W R/W R/W R/W R/W R/W
R R R R R R R R
0 0 0 0 0 0 0 0
GCTL_WPU_CFG I/O Pull-Up Configuration Register
b47 b46 b45 b44 b43 b42 b41 b40
WPU[47:40]
R/W R/W R/W R/W R/W R/W R/W R/W
R R R R R R R R
0 0 0 0 0 0 0 0
GCTL_WPU_CFG I/O Pull-Up Configuration Register
b39 b38 b37 b36 b35 b34 b33 b32
WPU[39:32]
R/W R/W R/W R/W R/W R/W R/W R/W
R R R R R R R R
0 0 0 0 0 0 0 0
GCTL_WPU_CFG I/O Pull-Up Configuration Register
b31 b30 b29 b28 b27 b26 b25 b24
WPU[31:24]
R/W R/W R/W R/W R/W R/W R/W R/W
R R R R R R R R
1 0 0 0 0 0 0 0
GCTL_WPU_CFG I/O Pull-Up Configuration Register
b23 b22 b21 b20 b19 b18 b17 b16
WPU[23:16]
R/W R/W R/W R/W R/W R/W R/W R/W
R R R R R R R R
0 0 0 0 0 0 0 0
GCTL_WPU_CFG I/O Pull-Up Configuration Register
b15 b14 b13 b12 b11 b10 b9 b8
WPU[15:8]
R/W R/W R/W R/W R/W R/W R/W R/W
R R R R R R R R
0 0 0 0 0 0 0 0
