Cypress EZ-USB FX3 User Manual

EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 305
GPIF_BUS_CONFIG2
0xE0014008
10.7.3 GPIF_BUS_CONFIG2
Bus Configuration Register #2
This register configures state number overrides directly using control signals CTRL[i] in the state number.
28:24 STATE7[4:0] Lambda number to be used for state number bit 7
20:16 STATE6[4:0] Lambda number to be used for state number bit 6
12:8 STATE5[4:0] Lambda number to be used for state number bit 5
2:0 STATE_FROM_CTRL[1:0] 0 Normal operation
1,2,3 STATE7 indicates Lambda number to be used for state number bit 7
2,3 STATE6 indicates Lambda number to be used for state number bit 6
3 STATE5 indicates Lambda number to be used for state number bit 5
GPIF_BUS_CONFIG2 Bus Configuration Register #2 0xE0014008
b31 b30 b29 b28 b27 b26 b25 b24
STATE7[4:0]
R/W R/W R/W R/W R/W
RRRRR
00000
GPIF_BUS_CONFIG2 Bus Configuration Register #2
b23 b22 b21 b20 b19 b18 b17 b16
STATE6[4:0]
R/W R/W R/W R/W R/W
RRRRR
00000
GPIF_BUS_CONFIG2 Bus Configuration Register #2
b15 b14 b13 b12 b11 b10 b9 b8
STATE5[4:0]
R/W R/W R/W R/W R/W
RRRRR
00000
GPIF_BUS_CONFIG2 Bus Configuration Register #2
b7 b6 b5 b4 b3 b2 b1 b0
STATE_FROM_CTRL[2:0]
R/W R/W R/W
RRR
000
Bit Name Description
