Cypress EZ-USB FX3 User Manual

EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 570
UART_INGRESS_DATA
0xE0000814
10.20.6 UART_INGRESS_DATA
UART Ingress Data Register
Presents ingress data 1 byte at a time. Reading from this register removes one byte from the FIFO if the FIFO has data avail-
able. It will result in ERROR if the FIFO is empty. The size of the receive FIFO is configured at design time.
7:0 DATA[7:0] Data byte read from the peripheral when DMA_MODE=0
UART_INGRESS_DATA UART Ingress Data Register 0xE0000814
b31 b30 b29 b28 b27 b26 b25 b24
UART_INGRESS_DATA UART Ingress Data Register
b23 b22 b21 b20 b19 b18 b17 b16
UART_INGRESS_DATA UART Ingress Data Register
b15 b14 b13 b12 b11 b10 b9 b8
UART_INGRESS_DATA UART Ingress Data Register
b7 b6 b5 b4 b3 b2 b1 b0
DATA[7:0]
RRRRRRRR
R/W R/W R/W R/W R/W R/W R/W R/W
00000000
Bit Name Description
