EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 533
I2S_INTR
0xE0000008
10.18.3 I2S_INTR
I2S Interrupt Request Register
Interrupt requests. Derived from STATUS register. Interrupt requests must be cleared by CPU and are generated regardless
of values in INTR_MASK register.
8 ERROR Set by hardware when corresponding STATUS asserts, cleared by software.
7 NO_DATA Set by hardware when corresponding STATUS asserts, cleared by software.
6 PAUSED Set by hardware when corresponding STATUS asserts, cleared by software.
5TXR_HALF Set by hardware when corresponding STATUS asserts, cleared by software.
4 TXR_SPACE Set by hardware when corresponding STATUS asserts, cleared by software.
3TXR_DONE Set by hardware when corresponding STATUS asserts, cleared by software.
2 TXL_HALF Set by hardware when corresponding STATUS asserts, cleared by software.
1TXL_SPACE Set by hardware when corresponding STATUS asserts, cleared by software.
0TXL_DONE Set by hardware when corresponding STATUS asserts, cleared by software.
I2S_INTR I2S Interrupt Request Register 0xE0000008
b31 b30 b29 b28 b27 b26 b25 b24
I2S_INTR I2S Interrupt Request Register
b23 b22 b21 b20 b19 b18 b17 b16
I2S_INTR I2S Interrupt Request Register
b15 b14 b13 b12 b11 b10 b9 b8
ERROR
R/W1C
R/W1S
0
I2S_INTR I2S Interrupt Request Register
b7 b6 b5 b4 b3 b2 b1 b0
NO_DATA PAUSED TXR_HALF TXR_SPACE TXR_DONE TXL_HALF TXL_SPACE TXL_DONE
R/W1C R/W1C R/W1C R/W1C R/W1C R/W1C R/W1C R/W1C
R/W1S R/W1S R/W1S R/W1S R/W1S R/W1S R/W1S R/W1S
00000000
Bit Name Description
