EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 249
GCTL_WPD_CFG
0xE0051028
10.4.6 GCTL_WPD_CFG
I/O Pull-Down Configuration Register
continued on next page
GCTL_WPD_CFG I/O Pull-Down Configuration Register 0xE0051028
b63 b62 b61 b60 b59 b58 b57 b56
WPD[59:56]
R/W R/W R/W R/W
R R R R
0 0 0 0
GCTL_WPD_CFG I/O Pull-Down Configuration Register
b55 b54 b53 b52 b51 b50 b49 b48
WPD[55:48]
R/W R/W R/W R/W R/W R/W R/W R/W
R R R R R R R R
0 0 0 0 0 0 0 0
GCTL_WPD_CFG I/O Pull-Down Configuration Register
b47 b46 b45 b44 b43 b42 b41 b40
WPD[47:40]
R/W R/W R/W R/W R/W R/W R/W R/W
R R R R R R R R
0 0 0 0 0 0 0 0
GCTL_WPD_CFG I/O Pull-Down Configuration Register
b39 b38 b37 b36 b35 b34 b33 b32
WPD[39:32]
R/W R/W R/W R/W R/W R/W R/W R/W
R R R R R R R R
0 0 0 0 0 0 0 0
GCTL_WPD_CFG I/O Pull-Down Configuration Register
b31 b30 b29 b28 b27 b26 b25 b24
WPD[31:24]
R/W R/W R/W R/W R/W R/W R/W R/W
R R R R R R R R
1 0 0 0 0 0 0 0
GCTL_WPD_CFG I/O Pull-Down Configuration Register
b23 b22 b21 b20 b19 b18 b17 b16
WPD[23:16]
R/W R/W R/W R/W R/W R/W R/W R/W
R R R R R R R R
0 0 0 0 0 0 0 0
GCTL_WPD_CFG I/O Pull-Down Configuration Register
b15 b14 b13 b12 b11 b10 b9 b8
WPD[15:8]
R/W R/W R/W R/W R/W R/W R/W R/W
R R R R R R R R
0 0 0 0 0 0 0 0
