PIB_WR_MAILBOX
0xE0010018
10.6.6 PIB_WR_MAILBOX
Write (Ingress) Mailbox Register
continued on next page
PIB_WR_MAILBOX Write (Ingress) Mailbox Register 0xE0010018
b63 b62 b61 b60 b59 b58 b57 b56
PP_WR_MAILBOX[63:56]
R R R R/W R/W R/W R/W R/W
R R R R R R R R
0 0 0 0 0 0 0 0
PIB_WR_MAILBOX Write (Ingress) Mailbox Register
b55 b54 b53 b52 b51 b50 b49 b48
PP_WR_MAILBOX[55:48]
R/W R/W R/W R/W R/W R/W R/W R/W
R R R R R R R R
0 0 0 0 0 0 0 0
PIB_WR_MAILBOX Write (Ingress) Mailbox Register
b47 b46 b45 b44 b43 b42 b41 b40
PP_WR_MAILBOX[47:40]
R/W R/W R/W R/W R/W R/W R/W R/W
R R R R R R R R
0 0 0 0 0 0 0 0
PIB_WR_MAILBOX Write (Ingress) Mailbox Register
b39 b38 b37 b36 b35 b34 b33 b32
PP_WR_MAILBOX[39:32]
R/W R/W R/W R/W R/W R/W R/W R/W
R R R R R R R R
0 0 0 0 0 0 0 0
PIB_WR_MAILBOX Write (Ingress) Mailbox Register
b31 b30 b29 b28 b27 b26 b25 b24
PP_WR_MAILBOX[31:24]
R/W R/W R/W R/W R/W R/W R/W R/W
R R R R R R R R
1 0 0 0 0 0 0 0
PIB_WR_MAILBOX Write (Ingress) Mailbox Register
b23 b22 b21 b20 b19 b18 b17 b16
PP_WR_MAILBOX[23:16]
R/W R/W R/W R/W R/W R/W R/W R/W
R R R R R R R R
0 0 0 0 0 0 0 0
PIB_WR_MAILBOX Write (Ingress) Mailbox Register
b15 b14 b13 b12 b11 b10 b9 b8
PP_WR_MAILBOX[15:8]
R/W R/W R/W R/W R/W R/W R/W R/W
R R R R R R R R
0 0 0 0 0 0 0 0
