EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 534
I2S_INTR_MASK
0xE000000C
10.18.4 I2S_INTR_MASK
I2S Interrupt Mask Register
Interrupt mask bits. Determine if INTR bits are reported to CPU. Have no effect on creation of INTR bits.
8 ERROR 1 Report interrupt to CPU
7 NO_DATA 1 Report interrupt to CPU
6 PAUSED 1 Report interrupt to CPU
5TXR_HALF 1 Report interrupt to CPU
4 TXR_SPACE 1 Report interrupt to CPU
3TXR_DONE 1 Report interrupt to CPU
2 TXL_HALF 1 Report interrupt to CPU
1TXL_SPACE 1 Report interrupt to CPU
0TXL_DONE 1 Report interrupt to CPU
I2S_INTR_MASK I2S Interrupt Mask Register 0xE000000C
b31 b30 b29 b28 b27 b26 b25 b24
I2S_INTR_MASK I2S Interrupt Mask Register
b23 b22 b21 b20 b19 b18 b17 b16
I2S_INTR_MASK I2S Interrupt Mask Register
b15 b14 b13 b12 b11 b10 b9 b8
ERROR
R/W
R
0
I2S_INTR_MASK I2S Interrupt Mask Register
b7 b6 b5 b4 b3 b2 b1 b0
NO_DATA PAUSED TXR_HALF TXR_SPACE TXR_DONE TXL_HALF TXL_SPACE TXL_DONE
R/W R/W R/W R/W R/W R/W R/W R/W
RRRRRRRR
00000000
Bit Name Description
