EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 511
PROT_SETUP_DAT
0xE0033438
10.16.7 PROT_SETUP_DAT
Received SETUP Packet Data Register
continued on next page
PROT_SETUP_DAT Received SETUP Packet Data Register 0xE0033438
b63 b62 b61 b60 b59 b58 b57 b56
SETUP_LENGTH[15:8]
R R R R R R R R
R/W R/W R/W R/W R/W R/W R/W R/W
0 0 0 0 0 0 0 0
PROT_SETUP_DAT Received SETUP Packet Data Register
b55 b54 b53 b52 b51 b50 b49 b48
SETUP_LENGTH[7:0]
R R R R R R R R
R/W R/W R/W R/W R/W R/W R/W R/W
0 0 0 0 0 0 0 0
PROT_SETUP_DAT Received SETUP Packet Data Register
b47 b46 b45 b44 b43 b42 b41 b40
SETUP_INDEX[15:8]
R R R R R R R R
R/W R/W R/W R/W R/W R/W R/W R/W
0 0 0 0 0 0 0 0
PROT_SETUP_DAT Received SETUP Packet Data Register
b39 b38 b37 b36 b35 b34 b33 b32
SETUP_INDEX[7:0]
R/W R/W R/W R/W R/W R/W R/W R/W
R R R R R R R R
0 0 0 0 0 0 0 0
PROT_SETUP_DAT Received SETUP Packet Data Register
b31 b30 b29 b28 b27 b26 b25 b24
SETUP_VALUE[15:8]
R R R R R R R R
R/W R/W R/W R/W R/W R/W R/W R/W
0 0 0 0 0 0 0 0
PROT_SETUP_DAT Received SETUP Packet Data Register
b23 b22 b21 b20 b19 b18 b17 b16
SETUP_VALUE[7:0]
R R R R R R R R
R/W R/W R/W R/W R/W R/W R/W R/W
0 0 0 0 0 0 0 0
PROT_SETUP_DAT Received SETUP Packet Data Register
b15 b14 b13 b12 b11 b10 b9 b8
SETUP_REQUEST[15:8]
R R R R R R R R
R/W R/W R/W R/W R/W R/W R/W R/W
0 0 0 0 0 0 0 0
