EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 512
PROT_SETUP_DAT
0xE0033438
10.16.7 PROT_SETUP_DAT (continued)
8-byte (2-long word) Storage for USB SETUP data received on EP0
63:48 SETUP_LENGTH[15:0] Setup data field
47:32 SETUP_INDEX[15:0] Setup data field
31:16 SETUP_VALUE[15:0] Setup data field
15:8 SETUP_REQUEST[7:0] Setup data field
7:0 SETUP_REQUEST_TYPE[7:0] Setup data field
PROT_SETUP_DAT Received SETUP Packet Data Register
b7 b6 b5 b4 b3 b2 b1 b0
SETUP_REQUEST_TYPE[7:0]
R R R R R R R R
R/W R/W R/W R/W R/W R/W R/W R/W
0 0 0 0 0 0 0 0
Bit Name Description
