EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 353
GPIF_LEFT_WAVEFORM
0xE0015000
10.7.44 GPIF_LEFT_WAVEFORM
Left Edge Waveform Memory Register
There are 256 GPIF_LEFT_WAVEFORM registers. The address of each is calculated as GPIF_LEFT_WAVEFORM(x) =
0xE0015000 + (x*0x10). Hence GPIF_LEFT_WAVEFORM(0) is at address 0xE0015000, GPIF_LEFT_WAVEFORM(1) is at
address 0xE0015000 + 0x10, and so on. The definition of each of these is the same.
continued on next page
GPIF_LEFT_WAVEFORM Left Edge Waveform Memory Register 0xE0015000
b127 b126 b125 b124 b123 b122 b121 b120
UNUSED
RRRRRRRR
RRRRRRRR
00000000
GPIF_LEFT_WAVEFORM Left Edge Waveform Memory Register
b119 b118 b117 b116 b115 b114 b113 b112
UNUSED
RRRRRRRR
RRRRRRRR
00000000
GPIF_LEFT_WAVEFORM Left Edge Waveform Memory Register
b111 b110 b109 b108 b107 b106 b105 b104
UNUSED
RRRRRRRR
RRRRRRRR
00000000
GPIF_LEFT_WAVEFORM Left Edge Waveform Memory Register
b103 b102 b101 b100 b99 b98 b97 b96
UNUSED
RRRRRRRR
RRRRRRRR
00000000
GPIF_LEFT_WAVEFORM Left Edge Waveform Memory Register
b95 b94 b93 b92 b91 b90 b89 b88
VALID BETA_DEASSERT REPEAT_COUNT[7:2]
R/W R/W R/W R/W R/W R/W R/W R/W
RRRRRRRR
00000000
GPIF_LEFT_WAVEFORM Left Edge Waveform Memory Register
b87 b86 b85 b84 b83 b82 b81 b80
REPEAT_COUNT[1:0] Beta[31:26]
R/W R/W R/W R/W R/W R/W R/W R/W
RRRRRRRR
00000000
GPIF_LEFT_WAVEFORM Left Edge Waveform Memory Register
b79 b78 b77 b76 b75 b74 b73 b72
Beta[25:18]
R/W R/W R/W R/W R/W R/W R/W R/W
RRRRRRRR
00000000
