Cypress EZ-USB FX3 User Manual

EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 614
SCK_INTR_MASK
0x14
10.25.6 SCK_INTR_MASK
Socket Interrupt Mask Register
The interrupt request bits in SCK_INTR function independent of the interrupt mask bits. The mask bits affect which interrupt
request bits are reported to CPU only.
9 LAST_BUF 1: Report interrupt to CPU
8 PARTIAL_BUF 1: Report interrupt to CPU
7 TRANS_DONE 1: Report interrupt to CPU
6 ERROR 1: Report interrupt to CPU
5 SUSPEND 1: Report interrupt to CPU
4STALL 1: Report interrupt to CPU
3 DSCR_NOT_AVL 1: Report interrupt to CPU
2 DSCR_IS_LOW 1: Report interrupt to CPU
continued on next page
SCK_INTR_MASK Socket Interrupt Mask Register 0x14
b31 b30 b29 b28 b27 b26 b25 b24
SCK_INTR_MASK Socket Interrupt Mask Register
b23 b22 b21 b20 b19 b18 b17 b16
SCK_INTR_MASK Socket Interrupt Mask Register
b15 b14 b13 b12 b11 b10 b9 b8
LAST_BUF PARTIAL_BUF
R/W1C R/W1C
W1S W1S
00
SCK_INTR_MASK Socket Interrupt Mask Register
b7 b6 b5 b4 b3 b2 b1 b0
TRANS_DONE ERROR SUSPEND STALL DSCR_NOT_AVL DSCR_IS_LOW
CONSUME_
EVENT
PRODUCE_
EVENT
R/W1C R/W1C R/W1C R/W1C R/W1C R/W1C R/W1C R/W1C
W1S W1S W1S W1S W1S W1S W1S W1S
00000000
Bit Name Description
