EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 382
UIB_INTR_MASK
0xE0030004
10.9.2 UIB_INTR_MASK
USB Interrupt Mask Register
Mask for UIB_INTR. Does not affect error logging, only reporting to VIC.
12 EPM_URUN_TIMEOUT SuperSpeed Egress EPM Interrupt
11 EPM_URUN SuperSpeed Egress EPM Interrupt
10 PROT_EP_INT SuperSpeed Device Endpoint Interrupt
9PROT_INT SuperSpeed Protocol Layer Interrupt
8 LNK_INT SuperSpeed Link Controller Interrupt
7 CHGDET_INT USB Charger Detect Interrupt
6OTG_INT USB OTG Interrupt
5 DEV_CTL_INT Device USB Control Interrupt
4 DEV_EP_INT Device EP Interrupt
continued on next page
UIB_INTR_MASK USB Interrupt Mask Register 0xE0030004
b31 b30 b29 b28 b27 b26 b25 b24
UIB_INTR_MASK USB Interrupt Mask Register
b23 b22 b21 b20 b19 b18 b17 b16
UIB_INTR_MASK USB Interrupt Mask Register
b15 b14 b13 b12 b11 b10 b9 b8
EPM_URUN_
TIMEOUT
EPM_URUN PROT_EP_INT PROT_INT LNK_INT
R/W1C R/W1C R R R
R/W1S R/W1S R/W R/W R/W
XXXXX
UIB_INTR_MASK USB Interrupt Mask Register
b7 b6 b5 b4 b3 b2 b1 b0
CHGDET_INT OTG_INT DEV_CTL_INT DEV_EP_INT OHCI_INT EHCI_INT HOST_EP_INT HOST_INT
RRRRRRRR
WWWWWWWW
XXXXXXXX
Bit Name Description
