Cypress EZ-USB FX3 User Manual

EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 550
I2C_PREAMBLE_DATA
0xE000041C
10.19.8 I2C_PREAMBLE_DATA
I
2
C Preamble Data Register
continued on next page
I2C_PREAMBLE_DATA I
2
C Preamble Data Register 0xE000041C
b63 b62 b61 b60 b59 b58 b57 b56
DATA[63:56]
R/W R/W R/W R/W R/W R/W R/W R/W
R R R R R R R R
0 0 0 0 0 0 0 0
I2C_PREAMBLE_DATA I
2
C Preamble Data Register
b55 b54 b53 b52 b51 b50 b49 b48
DATA[55:48]
R/W R/W R/W R/W R/W R/W R/W R/W
R R R R R R R R
0 0 0 0 0 0 0 0
I2C_PREAMBLE_DATA I
2
C Preamble Data Register
b47 b46 b45 b44 b43 b42 b41 b40
DATA[47:40]
R/W R/W R/W R/W R/W R/W R/W R/W
R R R R R R R R
0 0 0 0 0 0 0 0
I2C_PREAMBLE_DATA I
2
C Preamble Data Register
b39 b38 b37 b36 b35 b34 b33 b32
DATA[39:32]
R/W R/W R/W R/W R/W R/W R/W R/W
R R R R R R R R
0 0 0 0 0 0 0 0
I2C_PREAMBLE_DATA I
2
C Preamble Data Register
b31 b30 b29 b28 b27 b26 b25 b24
DATA[31:24]
R/W R/W R/W R/W R/W R/W R/W R/W
R R R R R R R R
0 0 0 0 0 0 0 0
I2C_PREAMBLE_DATA I
2
C Preamble Data Register
b23 b22 b21 b20 b19 b18 b17 b16
DATA[23:16]
R/W R/W R/W R/W R/W R/W R/W R/W
R R R R R R R R
0 0 0 0 0 0 0 0
I2C_PREAMBLE_DATA I
2
C Preamble Data Register
b15 b14 b13 b12 b11 b10 b9 b8
DATA[15:8]
R/W R/W R/W R/W R/W R/W R/W R/W
R R R R R R R R
0 0 0 0 0 0 0 0
