EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 551
I2C_PREAMBLE_DATA
0xE000041C
10.19.8 I2C_PREAMBLE_DATA (continued)
Contains the bytes that precede the data phase of the I2C command. This includes the slave address, R/W command, possi-
ble internal address and repeated start command. The number of bytes used is indicated in I2C_COMMAND.
63:0 DATA[63:0] Command and initial data bytes.
I2C_PREAMBLE_DATA I
2
C Preamble Data Register
b7 b6 b5 b4 b3 b2 b1 b0
DATA[7:0]
R/W R/W R/W R/W R/W R/W R/W R/W
R R R R R R R R
0 0 0 0 0 0 0 0
