EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 569

UART_EGRESS_DATA

0xE0000810

10.20.5 UART_EGRESS_DATA

UART Egress Data Register

Accepts egress data one byte at a time. Writing to this register adds one byte to the FIFO if the FIFO has space available. It

will result in ERROR if the FIFO is full. The size of the transmit FIFO is configured at design time.

7:0 DATA[7:0] Data byte to be written to the peripheral in registered mode.

UART_EGRESS_DATA UART Egress Data Register 0xE0000810

b31 b30 b29 b28 b27 b26 b25 b24

UART_EGRESS_DATA UART Egress Data Register

b23 b22 b21 b20 b19 b18 b17 b16

UART_EGRESS_DATA UART Egress Data Register

b15 b14 b13 b12 b11 b10 b9 b8

UART_EGRESS_DATA UART Egress Data Register

b7 b6 b5 b4 b3 b2 b1 b0

DATA[7:0]

WWWWWWWW

RRRRRRRR

00000000

Bit Name Description
