Cypress EZ-USB FX3 User Manual

EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 581
SPI_INTR_MASK
0xE0000C0C
10.21.4 SPI_INTR_MASK
SPI Interrupt Mask Register
Interrupt mask bits. Determine if INTR bits are reported to CPU. Have no effect on creation of INTR bits.
6 ERROR 1 Report interrupt to CPU
5TX_HALF 1 Report interrupt to CPU
4 TX_SPACE 1 Report interrupt to CPU
3 TX_DONE 1 Report interrupt to CPU
2 RX_HALF 1 Report interrupt to CPU
1 RX_DATA 1 Report interrupt to CPU
0 RX_DONE 1 Report interrupt to CPU
SPI_INTR_MASK SPI Interrupt Mask Register 0xE0000C0C
b31 b30 b29 b28 b27 b26 b25 b24
SPI_INTR_MASK SPI Interrupt Mask Register
b23 b22 b21 b20 b19 b18 b17 b16
SPI_INTR_MASK SPI Interrupt Mask Register
b15 b14 b13 b12 b11 b10 b9 b8
SPI_INTR_MASK SPI Interrupt Mask Register
b7 b6 b5 b4 b3 b2 b1 b0
ERROR TX_HALF TX_SPACE TX_DONE RX_HALF RX_DATA RX_DONE
R/W R/W R/W R/W R/W R/W R/W
RRRRRRR
0000000
Bit Name Description
