EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 509
PROT_ITP_TIME
0xE0033430
10.16.5 PROT_ITP_TIME
ITP Time Free Running Counter Register
This register contains a free running counter running at 125MHz (spread clock) and is used for the PROT_ITP_TIMESTAMP
time stamps.
23:0 COUNTER24[23:0] Current counter value.
PROT_ITP_TIME ITP Time Free Running Counter 0xE0033430
b31 b30 b29 b28 b27 b26 b25 b24
PROT_ITP_TIME ITP Time Free Running Counter
b23 b22 b21 b20 b19 b18 b17 b16
COUNTER24[23:16]
RRRRRRRR
R/W R/W R/W R/W R/W R/W R/W R/W
HHHHHHHH
PROT_ITP_TIME ITP Time Free Running Counter
b15 b14 b13 b12 b11 b10 b9 b8
COUNTER24[15:8]
RRRRRRRR
R/W R/W R/W R/W R/W R/W R/W R/W
HHHHHHHH
PROT_ITP_TIME ITP Time Free Running Counter
b7 b6 b5 b4 b3 b2 b1 b0
COUNTER24[7:0]
RRRRRRRR
R/W R/W R/W R/W R/W R/W R/W R/W
HHHHHHHH
Bit Name Description
