EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 385
UIB_POWER
0xE0037F04
10.9.4 UIB_POWER
Power, Clock, and Reset Control Registers
Every IP block will implement a few MMIO registers at offset 0x7F00 in its MMIO to space that identify the block and control its
power/clock/reset state. These registers are located in the CPU/Interconnect power and clock domains and are accessible
even when power/clock of the block is switched off.
31 RESETN Active LOW reset signal for all logic in the block. Note that reset is active on all flops in the block
when either system reset is asserted (RESET# pin or SYSTEM_POWER.RESETN is asserted) or
this signal is active.
After setting this bit to 1, firmware will poll and wait for the ‘active’ bit to assert. Reading ‘1’ from
‘resetn’ does not indicate the block is out of reset – this may take some time depending on initializa-
tion tasks and clock frequencies.
0 ACTIVE For blocks that must perform initialization after reset before becoming operational, this signal will
remain deasserted until initialization is complete. In other words, reading active = 1 indicates block is
initialized and ready for operation.
UIB_POWER Power, Clock, and Reset Control Registers 0xE0037F04
b31 b30 b29 b28 b27 b26 b25 b24
RESETN
R
W
0
UIB_POWER Power, Clock, and Reset Control Registers
b23 b22 b21 b20 b19 b18 b17 b16
UIB_POWER Power, Clock, and Reset Control Registers
b15 b14 b13 b12 b11 b10 b9 b8
UIB_POWER Power, Clock, and Reset Control Registers
b7 b6 b5 b4 b3 b2 b1 b0
ACTIVE
R/W
R
0
Bit Name Description
