Cypress EZ-USB FX3 User Manual

EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 386
PHY_CLK_AND_TEST
0xE0031008
10.10 USB2 HS/FS/LS PHY Registers
10.10.1 PHY_CLK_AND_TEST
USB PHY Clocks and Testability Configuration Register
H
30 ON_DCD MIPS PHY Enable Data Contact Detect Circuitry
29 SUSPEND_N Suspend value applied to USB2 PHY (active low)
27 RESET Reset value applied to USB2 PHY
25 VDATSRCEEN Vdat source enable for charger detect
24 CHGRDET MIPS PHY Charger Detector Output (0 = host detected, 1 = charger detected)
23 CHGRMODE MIPS PHY Charger Detector Mode
continued on next page
PHY_CLK_AND_TEST USB PHY Clocks and Testability Configuration Register 0xE0031008
b31 b30 b29 b28 b27 b26 b25 b24
ON_DCD SUSPEND_N RESET VDATSRCEEN CHGRDET
R/W R/W R/W R/W R
RR R RR/W
00 1 00
PHY_CLK_AND_TEST USB PHY Clocks and Testability Configuration Register
b23 b22 b21 b20 b19 b18 b17 b16
CHGRMODE CHGRDETEN CHGRDETON IDDIG IDPULLUP
R/W R/W R/W R R/W
RRRR/WR
100N0
PHY_CLK_AND_TEST USB PHY Clocks and Testability Configuration Register
b15 b14 b13 b12 b11 b10 b9 b8
PHY_CLK_AND_TEST USB PHY Clocks and Testability Configuration Register
b7 b6 b5 b4 b3 b2 b1 b0
VLOAD ONCLOCK DATABUS16_8
R/W R/W R/W
R RR
1 01
