DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
132
Figure 5-19 VLAN Interface Window
The fields that can be configured are described below:
Parameter Description
Unit
Select the Switch unit that will be used for this configuration here.
Click the Show Detail button to view more detailed information about the VLAN on the specific interface.
Click the Edit button to re-configure the specific entry.
After clicking the Show Detail button, the following page will appear.
Figure 5-20 VLAN Interface (VLAN Detail) Window
On this page, more detailed information about the VLAN of the specific interface is displayed.
Click the Back button to return to the previous page.
After click the Edit button, the following page will appear. This is a dynamic page that will change when a different
VLAN Mode is selected. When Access was selected as the VLAN Mode, the following page will appear.
