DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
243
Figure 6-40 RIP Settings (Edit) Window
Click the Back button to return to the previous window.
The fields that can be configured in Redistribution Configuration are described below:
Parameter Description
Redistribution
• First, select to enable or disable the RIP redistribution feature here.
• Second, select the routing protocol (domain) that will be redistributed into
RIP. Options to choose from are BGP, Connected, OSPF, Static, and
ISIS. The Static option means redistribute IP static routes. The Connected
option refers to routes that are established automatically through
configuring an IP address on an interface.
• Third, enter the value to be used as the metric for the redistributed route
here. The range is from 0 to 16.
• Fourth, enter the Route Map name that is used in the filtering of the routes
to be redistributed to the current routing protocol. If not specified, all routes
are redistributed.
Click the Apply button to accept the changes made.
The fields that can be configured in RIP Configuration are described below:
Parameter Description
Update Time
Enter the update interval in seconds at which the update message is sent. The
range is from 1 to 65535 seconds. Select the Default option to use the default
value here which is 30 seconds.
Invalid Time
Enter the invalid time value in seconds here. The range is from 1 to 65535
seconds. Select the Default option to use the default value here which is 180
seconds.
Flush Time
Enter the flush time value in seconds here. The range is from 1 to 65535 seconds.
Select the Default option to use the default value here which is 120 seconds.
Default Metric
Enter the default metric value here. The range is from 1 to 16. The default metric
is used in redistributing routes from other routing protocols. The routes being
redistributed are learned by other protocols and may have an incompatible metric
