DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
267
Figure 6-76 OSPFv2 Host Route Settings Window
The fields that can be configured in OSPFv2 Host Route Settings are described below:
Parameter Description
VRF Name
Enter the name of the VRF instance here. This name can be up to 12 characters
long. Click the Select VRF button to select a pre-configured VRF instance that will
be used here.
Area ID
Enter the OSPF area ID here.
Host IP
Enter the host IPv4 address here.
Cost
Enter the cost value for the stub entry here. The range is from 0 to 65535. Select
the Default option to use the default value, which is 1.
Click the Apply button to accept the changes made.
The fields that can be configured in OSPF Host Route Table are described below:
Parameter Description
VRF Name
Enter the name of the VRF instance here. This name can be up to 12 characters
long. Click the Select VRF button to select a pre-configured VRF instance that will
be used here.
Click the Find button to locate a specific entry based on the information entered.
Click the Delete button to delete the specified entry.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
After clicking the Select VRF button, the following page will appear.
Figure 6-77 OSPFv2 Host Route Settings (Select VRF) Window
Select the VRF entry and click the OK button to use the selected VRF entry.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
