DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
286
Parameter Description
interface does not receive the report packet before the leave timer expires, then
the interface’s membership will be removed from the group or channel that it is
leaving. The value of the leave timer is the value of the Last Listener Query
Interval times the Last Listener Query Count. The range is from 1 to 25 seconds.
Select the Default option to use the default value, which is 1 seconds.
Click the Back button to return to the previous window.
Click the Apply button to accept the changes made.
MLD Group Table
This window is used to find and display the MLD group information.
To view the following window, click L3 Features > IP Multicast Routing Protocol > MLD > MLD Group Table, as
shown below:
Figure 6-103 MLD Group Table Window
The fields that can be configured are described below:
Parameter Description
Interface VLAN
Enter the VLAN interface ID here. The range is from 1 to 4094.
Group
Enter the group IPv6 address here.
Click the Find button to locate a specific entry based on the information entered.
Click the Show All button to display all the entries.
MLD SSM Mapping Settings
This window is used to display and configure the MLD Source Specific Multicast (SSM) mapping settings.
To view the following window, click L3 Features > IP Multicast Routing Protocol > MLD > MLD SSM Mapping
Settings, as shown below:
