Figure 6-104 MLD SSM Mapping Settings Window
The fields that can be configured in MLD SSM Mapping Settings are described below:
Parameter Description
SSM Mapping State
Select to enable or disable the MLD SSM mapping feature here.
Click the Apply button to accept the changes made.
The fields that can be configured in Add Static SSM Mapping are described below:
Parameter Description
Source Address
Enter the source address that will be associated with the MLD membership for a
group here. This is identified by access list.
ACL Name
Enter the name of the standard IPv6 access list that will be used here. This name
can be up to 32 characters long. Click the Please Select button to select a pre-
configured access list to use here.
Click the Apply button to accept the changes made.
Click the Delete button to remove the specific entry.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
The fields that can be configured in MLD SSM Mapping Table are described below:
Parameter Description
Group Address
Enter the group address of the IPv6 multicast group to be displayed here.
Click the Find button to locate a specific entry based on the information entered.
After clicking the Please Select button, the following page will appear.
Figure 6-105 MLD SSM Mapping Settings (Please Select) Window
