Parameter Description
bucket for the two-rate metering.
Confirm Burst
Enter the confirm burst value here. This value must be between 0 and 16384
Kbytes. The confirm burst value specifies the burst size for the first token bucket
in kbps.
PIR
Enter the Peak Information Rate (PIR) value here. This value must be between 0
and 10000000 kbps. The peak information rate is the second token bucket for the
two-rate metering.
Peak Burst
Enter the peak burst value here. This value must be between 0 and 16384
Kbytes. The peak burst value is the burst size for the second token bucket in
kilobytes.
Confirm Action
Select the confirm action here. The confirm action specifies the action to take on
green color packets. If the confirm action is not specified, the default action is to
Transmit. Options to choose from are Drop, Set-DSCP-Transmit, Set-1P-
Transmit, Transmit, and Set-DSCP-1P.
• When selecting the Drop option, the packet will be dropped.
• When selecting the Set-DSCP-Transmit option, enter the IP DSCP value in
the space provided. This value sets the IP differentiated services code point
(DSCP) value and transmits the packet with the new IP DSCP value.
• When selecting the Set-1P-Transmit option, enter the 1P transmit value in
the space provided. This value sets the 802.1p value and transmits the
packet with the new value.
• When selecting the Transmit option, packets will be transmitted unaltered.
• When selecting the Set-DSCP-1P option, enter the IP DSCP and 1P transmit
values in the spaces provided.
Exceed Action
Select the exceed action here. The exceed action specifies the action to take on
packets that exceed the rate limit. For a two rate policer, if the exceed action is
not specified, the default action is Drop. Options to choose from are Drop, Set-
DSCP-Transmit, Set-1P-Transmit, Transmit, and Set-DSCP-1P.
• When selecting the Drop option, the packet will be dropped.
• When selecting the Set-DSCP-Transmit option, enter the IP DSCP value in
the space provided. This value sets the IP differentiated services code point
(DSCP) value and transmits the packet with the new IP DSCP value.
• When selecting the Set-1P-Transmit option, enter the 1P transmit value in
the space provided. This value sets the 802.1p value and transmits the
packet with the new value.
• When selecting the Transmit option, packets will be transmitted unaltered.
• When selecting the Set-DSCP-1P option, enter the IP DSCP and 1P transmit
values in the spaces provided.
Violate Action
Select the violate action here. The violate action specifies the action to take on
packets that violate the normal and maximum burst sizes for singe rate policing. It
specifies the action to take for those packets that did not conform to both CIR and
PIR. For a single rate policer, if the violate action is not specified, it will create a
single-rate two-color policer. For a two-rate policer, if the violation action is not
specified, the default action is equal to the exceed action. Options to choose from
are Drop, Set-DSCP-Transmit, Set-1P-Transmit, Transmit, and Set-DSCP-1P.
• When selecting the Drop option, the packet will be dropped.
• When selecting the Set-DSCP-Transmit option, enter the IP DSCP value in
the space provided. This value sets the IP differentiated services code point
(DSCP) value and transmits the packet with the new IP DSCP value.
• When selecting the Set-1P-Transmit option, enter the 1P transmit value in
the space provided. This value sets the 802.1p value and transmits the
packet with the new value.
