DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
536
Figure 10-7 CFM Settings (Add MA, Add MEP, MEPID Detail, Edit) Window
The fields that can be configured are described below:
Parameter Description
MEP State
Select to enable or disable the MEP state on the interface here.
CCM State
Select to enable or disable the CCM state here.
PDU Priority
Select the PDU priority value here. The range is from 0 to 7. This feature is used
to define the 802.1p priority that is set in the CCM and other CFM PDUs
transmitted by the MEP.
Fault Alarm
Select the type of defects whose fault alarms can be sent by this MEP. Options to
choose from are None, All, MAC-Status, Remote-CCM, Error-CCM, and XCON-
CCM.
• None - Specifies that no fault alarm will be sent.
• All - Specifies that the fault alarms can be sent for all types of defects.
• MAC-Status - Specifies that the fault alarms can be sent for the defects
whose priority is equal to or higher than DefMACstatus.
• Remote-CCM - Specifies that the fault alarms can be sent for the defects
whose priority is equal to or higher than DefRemoteCCM.
• Error-CCM - Specifies that the fault alarms can be sent for the defects
whose priority is equal to or higher than DefErrorCCM.
• XCON-CCM - Specifies that only the fault alarm of DefXconCCM can be
