DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
597
The fields that can be configured for Mirror Settings are described below:
Parameter Description
Session Number
Select the mirror session number for this entry here. This number is between 1
and 4.
Destination
Tick the checkbox, next to the Destination option, to configure the destination for
this port mirror entry.
In the first drop-down menu select the destination type option. Options to choose
from are Port, Remote VLAN, and Replace.
• Port - After selecting this option, select the Switch Unit ID and destination
Port number from the drop-down menus.
• Remote VLAN - After selecting this option, select the Switch Unit ID and
destination Port number from the drop-down menus and enter the VID in the
space provided. The VID must be between 2 and 4094.
• Replace - After selecting this option, enter the ACL Access List name and
VID (VLAN ID) in the spaces provided.
Source
Tick the checkbox, next to the Source option, to configure the source for this port
mirror entry.
In the first drop-down menu select the source type option. Options to choose from
are Port, ACL, VLAN, and Remote VLAN.
• Port - After selecting this option, select the Switch Unit ID, From Port and
To Port numbers from the drop-down menus. Lastly select the Frame Type
option from the last drop-down menu. Options to choose from are Both, RX,
TX, and TX Forwarding. When selecting Both, traffic in both the incoming
and outgoing directions will be mirrored. When selecting RX, traffic in only
the incoming direction will be mirrored. When selecting TX, traffic in only the
outgoing direction will be mirrored. Select the CPU RX option to also monitor
CPU RX traffic.
• ACL - After selecting this option, enter the ACL Name in the space provided.
• VLAN - After selecting this option, enter the VID List in the space provided
and select the Frame Type from the drop-down menu.
• Remote VLAN - After selecting this option, enter the VID in the space
provided. The VID must be between 2 and 4094.
Click the Add button to add the newly configured mirror entry based on the information entered.
Click the Delete button to delete an existing mirror entry based on the information entered.
The fields that can be configured for Mirror Session Table are described below:
Parameter Description
Mirror Session Type
Select the mirror session type of information that will be displayed from the drop-
down menu. Options to choose from are All Session, Session Number, Remote
Session, and Local Session.
After selecting the Session Number option, select the session number from the
second drop-down menu. This number is from 1 to 4.
Click the Find button to locate a specific entry based on the information entered.
Click the Show Detail button to view more detailed information about the mirror session.
After clicking the Show Detail button, the following window will appear:
