Caratteristiche tecniche
Technical specification
sezione / section
C 1.1
14
A
B
C
D
E
F
G
H
L
M
N
P
ST3 - M.Y. 2004 - edizione/edition 00
Front suspension
Rear wheel
Rear suspension
Reference Specifications
Type Hydraulic upside down fork with adjustable
spring preload, Ø 43 stanchions
Fork Travel along legs axis 130 mm
Adjustable only in spring preload
Spring preload Standard setting 18 mm (adjustment range
10 — 25 mm)
Volume of oil per leg 0.504 Dm
3
Reference Standard value Max. allowed value
Tread min. thickness In the most worn position 2 mm
Tyre pressure (Cold) With rider and luggage 2.1 bar 2.14 kg/cm
2
—
2.3 bar / 2.34 kg/cm
2
With rider, passenger and luggage 2.2 bar 2.24 kg/cm
2
—
2.4 bar / 2.44 kg/cm
2
Swingarm shaft eccentricity On 100 mm 0.2 mm
Wheel rim eccentricity Radial 0.8 mm 2 mm
Axial 0.5 mm 2 mm
Chain Make
Type
DID
525 HV
Dimensions 5/8" x 5/16"
No. of links 102
Reference Specifications
Type Progressive monoshock featuring fully
adjustable compression, rebound and preload.
Shock-absorber Travel 65 mm
Hydraulic damping standard setting.
Turn out the adjuster from fully closed position
(clockwise)
Compression: 12 clicks
Rebound: 2 turns
Spring preload 18 mm
Preloaded spring length 149.5 mm
Wheel travel 148 mm
