Ducati ST3 2004 User Manual

Caratteristiche tecniche
Technical specification
sezione / section
C 3
27
A
B
C
D
E
F
G
H
L
M
N
P
ST3 - M.Y. 2004 - edizione/edition 00
3 - TORQUE SETTINGS
Frame torque settings
Part Thread (mm) Nm ±10% tolerance Notes
Front Sprocket Chain
Front sprocket retaining nut 186 (•) GREASE B
Front sprocket holder retaining screw M 5x0.8 6(•) LOCK 1
Front sprocket cover screw M 6x1 9
Optical Devices
Headlight mounting to frame retaining nut M 8x1.25 24
Tail light retaining nuts M6x1 6
Number plate light retaining nuts M5x0.8 1.5
Reflector retaining nuts M4x0.7 2
Absolute pressure adjuster screw M 4x0.7 2
Headlight to mounting retaining screw M6x1 9
Intake duct flange to headlight mounting
retaining screw
M 5x0.8 5
Turn indicator retaining screw M6x1 3.2
Headlight mounting shell retaining screw M 5x0.8 5
Voltage regulator to headlight mounting
retaining screw
M 6x1 9
Instruments
Instrument panel mounting studs M6x1 5 LOCK 1
Instrument panel to yoke retaining nuts 5
Multi-functional display retaining nut M5x0.8 5
Rev counter to mounting retaining nut M5x0.8 5
Odometer to mounting plate retaining nut M6 5
Instrument panel side guard mounting post
retaining screw
M 5x0.8 5
Odometer cable ring nut at instrument panel
and drive
M12x1 3
Front Fork
Steering head screws M8x1.25 23(•) GREASE B
Bottom yoke screw M8x1.25 20(•) GREASE B
1-2-1 sequence
Fork bottom screw M 8x1.25 19 (•) GREASE B
1-2-1 sequence
Steering stop lock nut M8x1.25 18 LOCK 2
(on nut threads only)
Steering stop lock nut M35x1 30 GREASE D
Fork splash guard screw M5x0.8 5.5 LOCK 2
Electric System
Horn retaining screw M8x1.25 24 LOCK 2
LH and RH switch group screw M4x0.7 3
Ignition key switch retaining screw M6x1 9 LOCK 1
Battery cable screws M5x1 6
