Battery mounting post to horizontal head
retaining screw
M 6x1 9 LOCK 2
Starter motor retaining nut M6x1 5 GREASE B
Horn bracket retaining nut M12x1 20
Starter switch mounting retaining nut M6x1 4
Coil to fairing mounting retaining screw M6x1 9
Terminal board to headlight mounting
retaining screw
M5x0.8 2.3
Plate-to-coil retaining screw M4x0.7 3
Vertical cylinder coil bracket to filter box
retaining screw
M 6x1 6
Fuse holder mounting plate retaining screw M6x1 1.8
Battery mounting to frame retaining screw
and battery mounting to post on horizontal
head retaining screw
M6x1 9
Power socket retaining ring nut 2.5
Immobilizer antenna cable guide to headlight
mounting retaining screw
M 5x0.8 9
Terminal board-to-front frame section
retaining screw
M5x0.8 2.3
1.8 control unit to frame retaining screw M 6x1 5
Front Brake
Front brake caliper retaining screw M10x1.25 43(•) GREASE B
Front brake master cylinder retaining screw M6x1 9 1 (UP)-2-1 sequence
Front and rear disk retaining screw M 8x1.25 30 (Nm±2%) (•) LOCK 2
Brake bleed union M16x1 12
Front/rear brake bleed valve M 10x1 23
Front brake hose guide retaining screw M6x1 10
Rear Brake
Rear brake caliper retaining screw M8x1.25 25(•) GREASE B
Rear brake master cylinder to bracket
retaining screw
M 6x1 10
Rear brake master cylinder bracket to
casing retaining screw
M10x1.5 43 LOCK 5
Rear brake pedal pin M10x1.5 29 LOCK 5
Rear brake hose guide retaining screw M5x0.8 5
Rear brake fluid reservoir retaining screw M8x1.25 15
Rear brake pedal switch retaining screw 5
Rear brake pedal adjuster screw 2.3
Rear brake linkage nut M6x1 7.5
Swingarm
Swingarm shaft screw M10x1.5 43(•) GREASE B
Chain tensioner adjuster M8x1.25 8 GREASE B
Chain slide retaining screw M6x1 5.5 LOCK 1
Chain tension adjustment lock screw M3x0.5 1.7
Part Thread (mm) Nm ±10% tolerance Notes
