Ducati ST3 2004 - Page 60

Caratteristiche tecniche
Technical specification
sezione / section
C 3
29
A
B
C
D
E
F
G
H
L
M
N
P
ST3 - M.Y. 2004 - edizione/edition 00
Handlebars and clutch control
Throttle control retaining screw M6x1 9
Handlebar clamp pinch bolts M 6x1 10 (•) GREASE B
Sequence 1-2-1
Clutch master cylinder to handlebar
retaining screw
M 6x1 9 Sequence 1(UP)-2-1
Counterweight retaining screw M8x1.25 23 LOCK 1
Clutch hose union M 10x1 19
Clutch operator retaining screw M 6x1 9 Sequence 1(UP)-2-1
Throttle control cover retaining screw M 4x0.7 1.8
Rear Shock Absorber
Monoshock top screw M10x1.25 42(•) GREASE B
Monoshock bottom screw M10x1.25 42(•) GREASE B
Suspension link top screw M10x1.25 42(•) GREASE B
Monoshock gas cylinder to RH rear frame
retaining screw
M 6x1 9
Ball joint to reaction arm retaining nut M12x1.5 36
Rocker arm to frame retaining nut M12x1.5 75(•) GREASE B
Front and Rear Mudguards
Rear mudguard retaining screw M 6x1 3 LOCK 2
Front mudguard retaining screw M6x1 3 LOCK 2
Storage compartment retaining screw M 6x1 9 LOCK 2
Number plate holder back plate retaining nut 4
Seat lock retaining screw M 5x0.8 2.5
Number plate holder retaining screw M5x0.8 9
Footpegs and control levers
Front and rear footpeg bracket retaining
screw
M8x1.25 24 LOCK 2
Rider heal guard retaining screw M5x0.8 5 LOCK 2
Gear change pedal retaining screw M6x1 9 LOCK 1
Gear change pedal shaft M8x1.25 23 LOCK 2
Lift handle to footpeg bracket retaining screw M8x1.25 20
Front and Rear Wheels
Left front wheel nut M25x1.25 63(•) GREASE B
Rear wheel nut M25x1.25 83(•) GREASE B
Rear sprocket retaining nut M10x1.25 46(•) LOCK 2
Rear wheel transmission damper shaft M14x1.5 46(•) LOCK 8
Fuel Tank
Tank retaining nuts M6x1 8
Tank drain plug M10x1.25 10 LOCK 6
Filler cap retaining screw M5x0.8 5
Tank drain/breather hose clamp 2
Fuel hose clamp 1.6
Part Thread (mm) Nm ±10% tolerance Notes
