Caratteristiche tecniche
Technical specification
sezione / section
C 3
30
A
B
C
D
E
F
G
H
L
M
N
P
ST3 - M.Y. 2004 - edizione/edition 00ST3-
Delivery and return hose unions to tank
flange retaining screws
M 12x1.25 33 LOCK 6
Tank support buffer retaining screw M 6x1
Fuel tank pads screw M6x1 9
Exhaust System
Exhaust pipe clamp screw M8x1.25 23
Stainless steel exhaust plugs 1/8gas/inox 25
Silencer to footpeg bracket retaining screw M8x1.25 24
Seat
Storage compartment retaining screw M6x1 9 LOCK 2
Number plate holder retaining screw M 5x0.8 9
Number plate holder back plate retaining nut 4
Seat lock ring nut M22x1.5 1 LOCK 3
Seat lock retaining screw M5x0.8 2.5
Air Intake and Oil Breather
Oil vapors valve clamp 1.9
Oil breather tank hose clamp 1.2
Oil breather tank retaining screw M6x1 2
Filter box mounting post retaining screw M5x0.8 6
Filter box retaining screw M6x1 9
Intake horn spring retaining screw M5x0.8 3 LOCK 2
Throttle body retaining clamp 1.5
Expansion tank retaining screw M 6x1 9
CANISTER
Canister hose to manifold union retaining
screw
1.5
Canister bracket retaining screw M 6x1 9 USA version only
Fairing
Fairing mounting retaining screw M6x1 9 LOCK 1
Side panel to frame retaining screw M 5x0.8 4 LOCK 1
Rear side panel to handle retaining screw M 6x1 6
Rear handle retaining screw M6x1 9(•) LOCK 2
Side panel clamp to frame retaining screw M6x1 6 LOCK 2
Front and rear dash panel to headlight
fairing retaining screw
M 5x0.8 2.5
Windshield retaining screw 0.6
Fairing retaining screw M5x0.8 2.5
Handle cover retaining screw M6x1 2.5
Mesh to front shield retaining screw 1.2
Fairing, central duct, front shield, headlight
fairing and side panel retaining screw
1.5
Rear-view mirror retaining screw 3.5
Front fairing and central duct retaining screw M6x1 1.5
Part Thread (mm) Nm ±10% tolerance Notes
