Caratteristiche tecniche
Technical specification
sezione / section
C 3
31
A
B
C
D
E
F
G
H
L
M
N
P
ST3 - M.Y. 2004 - edizione/edition 00
(•) Tightening torque tolerance Nm ± 5%.
Note
See Section A 2 for technical specifications and symbols.
Stand
Side stand plate retaining screw M10x1.5 43 LOCK 5
Side stand pivot retaining nut M8x1.25 26
Center stand retaining screw M10x1.25 43 LOCK 5
Center stand pivot retaining nut M10x1.5 43 GREASE A
Side stand switch retaining screw M6x1 10
Frame
Fuel tank hinge to frame retaining screw M 6x1 9
Engine to frame mounting bolt nut 12x1.25 60 (•) GREASE B
Oil cooler
Oil cooler union on cooler M 14x1.5 23 LOCK 1
Hold cooler hexagon
steady.
Oil cooler plug M 10x1 20 LOCK 2
Cylinder head oil delivery hose union on
cooler
15 Engine oil
Oil cooler retaining screw M5x0.8 9 Engine oil
Oil hose union on cooler with double O ring
(Twin Seal)
M16x1.5 18 (•) Engine oil
Oil hose union on casing with double O ring
(Twin Seal)
M16x1.5 18 (•) Engine oil
Liquid Cooling System
Expansion tank hose clamp 1.5
Coolant drain plug on pump cover M5x0.8 18
Coolant hose clamps 2.5
Expansion tank retaining screw M6x1 9
Part Thread (mm) Nm ±10% tolerance Notes
