Ducati ST3 2004 - Page 65

Caratteristiche tecniche
Technical specification
sezione / section
C 3
34
A
B
C
D
E
F
G
H
L
M
N
P
ST3 - M.Y. 2004 - edizione/edition 00ST3-
Note
See Section A 2 for technical specifications and symbols.
Flywheel/ rotor retaining screws M 6x1 13 LOCK 2 or THREE
BOND 1324
Gearbox bearing stop plate retaining screws M 6x1 10 LOCK 2 or THREE
BOND 1324
Coolant drain plug on union M 6x1 8 (•) LOCK 2 or THREE
BOND 1324
Intake manifold fuel pump union M 6x1 2,5 LOCK 2 or THREE
BOND 1324
Bosch pick-up retaining screw M 6x1 10 LOCK 2 or THREE
BOND 1324
Liquid recovery tank bracket retaining screw M 6x1 9
Battery mounting bottom stud M 6x1 10 LOCK 2 or THREE
BOND 1324
Gearbox pawl retaining screw M 6x1 9 LOCK 2 or THREE
BOND 1324
Cylinder / head coolant cover screws M 6x1 6 (•)
Inspection cover retaining screws M 6x1 4,5 (•)
Cylinder head coolant outlet union screws M 6x1 10
Rocker arm shaft cover screws M 6x1 10
Intake/exhaust valve cover screws M 6x1 10
Clutch cover screws M 6x1 9
Alternator cover screws M 6x1 10
Nuts and bolts in general M 6x1 10
Intake manifold plug M 5x0.8 3 (•)
Clutch spring screws M 5x0.8 5 GREASE A
Manifold nipple M 5x0.8 3 LOCK 2 or THREE
BOND 1324
Nuts and bolts in general M 5x0.8 5
Coolant hose clamps 2.5
Part Thread (mm) Nm tolerance ±10% Notes
