Ducati ST3 2004 - Page 64

Caratteristiche tecniche
Technical specification
sezione / section
C 3
33
A
B
C
D
E
F
G
H
L
M
N
P
ST3 - M.Y. 2004 - edizione/edition 00
Clutch-side casing service cap M 10x1.5 15 LOCK 5 or THREE
BOND 1375B
Nuts and bolts in general M 10x1.5 45
Neutral light switch M 10x1.25 10
Con-rod bolts: 1st step: approach
2nd step: app
tighten to yield point with
torque and angular counteract.
M 10x1 20 (min. 19 max. 21)
35 (min. 33 max. 37)
(70/103)
55°/95°
GREASE B
Pressure switch M 10x1 19
Adapter bush M 10x1 LOCK 5 or THREE
BOND 1375B
Spark plugs M 10x1 15
Sump bottom drain plug M 12x1.5 20
Coolant pump cover plug M 10x1 20
Exhaust side oil circuit plug M 10x1 15 LOCK 2 or THREE
BOND 1324
Ground connection screw M 8x1.5 13
Crankshaft grub screws M 8x1.25 13 THREE BOND 1375B
Gear stop retaining screw M 8x1.25 18 LOCK 2 or THREE
BOND 1324
Oil pump retaining screws M 8x1.25 26
Clutch drum retaining screws M 8x1.25 35 (•) LOCK 4
Casing drilled screw M 8x1.25 20 GREASE B
Fixed tensioner pin M 8x1.25 26 LOCK 2 or THREE
BOND 1324
Mobile tensioner pin M 8x1.25 26 LOCK 2 or THREE
BOND 1324
Fluid recovery breather screw M 8x1.25 2.2
Tensioner eccentric nut M 8x1.25 25 GREASE A
Clutch spring screws (Adler) M 6x1 6
Stator cable bracket retaining screws M 6x1 10 LOCK 2 or THREE
BOND 1324
Casing jointing screw: 1st tightening
Final torque
M 8x1.25 19 (min. 17 max. 21)
25 (min. 22 max. 28)
GREASE B
Nuts and bolts in general M 8x1.25 25
Gear pawl retaining screw M 8x1.25 25
Intake and exhaust flange studs M 6x1 5 (•) LOCK 2 or THREE
BOND 1324
Intake manifold nuts M 6x1 10
Casing joint screws M 6x1 9
Starter motor retaining screws M 6x1 10 LOCK 2 or THREE
BOND 1324
Starter idle gear shaft screw M 6x1 10 LOCK 2 or THREE
BOND 1324
Coolant pump bearing retaining screw M 6x1 10 LOCK 2 or THREE
BOND 1324
Alternator stator retaining screws M 6x1 10 LOCK 2 or THREE
BOND 1324
Part Thread (mm) Nm tolerance ±10% Notes
