Repairs/Adjustments 08/20/2015 GBC AdvancedPunch Pro
4-20
Installation Procedure
1. Place the Docking Bracket in position and tighten the (2x) screws at
the rear side of the Docking Bracket.
2. Tighten the (1x) screw at front side of the Docking Bracket
3. Place the Docking latch bracket and tighten (2x) screws.
4. Do GP 6.3 Dock the Punch to connect the Punch to the upstream
and downstream devices.
5. Connect the Power Cord.
6. Power ON the entire printing system.
To Next Page
