GBC AdvancedPunch Pro - Defect Entry RAP Procedure; Punch Quality

GBC AdvancedPunch Pro 11/07/2018 Punch Quality
3-3
3.1 Punch Quality
This section contains information related to the quality of the output
such as hole quality or alignment.
3.2 Defect Entry RAP Procedure
Inspect the quality of the punch by referring to the specifications for
Punch position and registration.
1. Do GP 6.1.10 DIE CYCLES Procedure to check the cycle life
on the Die Set installed in the AdvancedPunchPro.
2. If any of the Die Set life cycles have exceeded 750,000 sheets
(cycles) go to Section 3 and check the Punch Quality.
DIE CYCLES
750,129
• If the Punch Quality is acceptable monitor the Punch Quality
frequently to ensure that the Punch Quality is okay.
• If the Hole Quality is not acceptable replace the Die Set.
3. Defects in the appearance of the punch such as hole skew or
non-uniformity are diagnosed in the following sections.
