GBC AdvancedPunch Pro Service Manual

Parts List 09-11-2018 GBC AdvancedPunch Pro
5-36
10.Part Number Index
Part #
XEROX
PART #
DESCRIPTION
PL
1823901
B
026N00825
B
SCREW,PHILLIPS W/SEMS,M3X6
5.4
5.6
5.25
5.31
7715838
002N03215
COVER, SIDE FRAME, DOWNSTREAM,
UPPER
5.4
1824001
B
027N00262
B
NUT, KEPS M4
5.4
5.6
5.7
5.21
7715565
030N00801
DOCKING BRACKET
5.4
7610501
110N01437
INTERLOCK SWITCH
5.4
5.12
7706447
121N01242
MAGNET, FRONT DOOR
5.4
7706486
003N01055
LATCH, PUSH TO CLOSE
5.4
7715267
127N07842
EXHAUST FAN
5.4
7715527
123N0269
LCD, DISPLAY
5.4
7715553
002N03190
FRONT DOOR ASSEMBLY
5.4
7715557
002N03225
TOP COVER ASSEMBLY
5.4
7715562
002N03226
REAR COVER ASSEMBLY
5.4
7715564
002N03227
UPSTREAM REAR SIDE COVER
5.4
7715572
002N03228
COVER,SIDE,DOWNSTREAM, FRONT
5.4
7715843
002N03216
COVER, POWER CORD
5.4
7715576
002N03229
DOWNSTREAM REAR SIDE CVR
5.4
7715844
026N00838
CAPTIVE SCREW, M4X0.7, 5MM
5.4
7715632
B
026N00829
B
SCREW, ROUND TIP, M4 X 8
5.4
7715682
002N03205
PANEL, LCD MEMBRANE
5.4
7715686
002N03230
COVER,SIDE FRAME,UPSTREAM
5.4
7715687
002N03231
COVER, SIDE FRAME, DOWNSTREAM,
LOWER
5.4
7715569
030N00799
FRONT DOOR TOP HINGE
5.4
7715782
030N00797
FRONT DOOR TOP HINGE
5.4
7715570
030N00798
FRONT DOOR BOTTOM HINGE
5.4
7715783
074N00073
FRONT DOOR BOTTOM HINGE
5.4
7715684
007N01788
DRIVE,USB STICK, FLASH DRIVE
5.4
7715828
002N03218
USB DRIVE COVER
5.4
7715101
002N03202
PANEL, ENTRANCE, LOWER
5.5
7715690
002N03204
PANEL, EXIT, LOWER
5.5
7715424
002N03191
PANEL ASSEMBLY, LOWER, EXIT
5.5
Part #
XEROX
PART #
DESCRIPTION
PL
7715209
006N01358
SHAFT, IDLER PANEL HINGE
5.5
7715210
006N01359
SHAFT,IDLR PANEL HINGE,LONG
5.5
7715150
002N03195
PANEL WELDMENT, DRIVE, EXIT
5.5
7715128
002N03192
PANEL WELDMNT, BYPASS,LOWER
5.5
1821209
D
013N13951
D
SNAP-IN BEARING, 6MM ID, [QTY. (2)
USED ON ALL IDLER PANELS- #A, #B,
#D, #E AND #3
5.5
5.6
5.7
1822202
A
028N00369
A
E-RING, JE-5
5.6
5.7
5.8
5.25
1823711
B
027N00258
B
JAM NUT, M16X2.0
5.6
1823909
B
026N00822
B
SCREW, HX, W/SEMS M4X6
5.6
1821606
B
026N00816
B
SCREW, PHILLIPS PAN HD, M3X10
5.6
7715195
121N01243
MAGNET, PANEL, OPEN, STRONG
5.6
7715215
003N01110
HANDLE, ACCEL IDLER LATCH
5.6
7715385
121N01240
MAGNET, BRACKET, ASSY
5.6
7715427
005N00686
CHIP TRAY, ASSEMBLY
5.6
7715650
003N01106
LATCH, BYPASS
5.6
7715637
105N02293
POWER SUPPLY, 24V, MW SP 480,
5.6
5.9
7715789
121N01244
MAGNET, PANEL, OPEN, WEAK
5.6
7708163
021N02267
CAP, RUBBER, RAIN BLUE
5.6
5.15
5.16
5.17
5.18
7715630
017N00300
CASTER, ADJUSTABLE
5.6
A
7715973
600N03432
KIT, HARDWARE, RINGS
B
7715974
600N03433
KIT, HARDWARE, FASTENERS
C
7715975
600N03434
KIT, HARDWARE, WASHERS
D
7715976
600N03435
KIT, HARDWARE, BEARINGS
E
7715977
600N03436
KIT, HARDWARE, WIRE CLAMPS
F
7715978
600N03437
KIT, HARDWARE, SPRINGS
