GBC AdvancedPunch Pro Service Manual

GBC AdvancedPunch Pro 11/07/2018 Punch Quality
3-11
This clears the fault
Yes- Return to normal operation; No- Go to Step 2
2. Check the function of Sensor S1b. See GP 6.2.7 Sensor
Procedure.
Sensor S1b functions properly
Yes- Escalate to next level; No- Go to Step 3
3. Ensure the sensor S1b is connected properly on the receiver
side and emitter side.
Sensor S1b is connected properly
Yes- Escalate to next level; No- Go to Step 4
4. Replace defective S1b receiver or emitter if needed.
New S1b sensors correct the issue.
Yes- Continue normal operation; No- Escalate to next level.
3.14 Punch Specifications
Speed
Up to 157 sheets per minute
Punch Sheet Size and
Edge
LEF- Long Edge Fed
SEF- Short Edge Fed
US Sizes
LTR LEF
LTR SEF
Statement LEF
Legal SEF
Ledger SEF
9” x 12” SEF
9” x 12” LEF
12” x 18” SEF
DFA Configurations offer Double
Punching below sizes:
LTR SEF; Ledger SEF;
9x12 SEF; 12x18 SEF
ISO sizes
A4 LEF
A4 SEF
A5 LEF
A3 SEF
SRA4 SEF
SRA4 LEF
SRA3 SEF
DFA Configurations offer Double
Punching below sizes:
A4 SEF; A3 SEF; SRA4 SEF;
SRA3 SEF
Paper Stock for Punch
job
Plain: 75gsm - 300gsm
(20# bond to 110# cover)
Coated: 120gsm - 300gsm
(32# bond to 110# cover)
Bypass Mode Sheet size
Paper sizes and stocks same as
printer

GBC AdvancedPunch Pro Specifications
